19" 1U Rack Mounted Optical Plc Splitter 1x16 Cold Rolled Steel Material

Name: 19quot 1U Rack Mounted Optical Plc Splitter 1x16 Cold Rolled Steel Material
Brand: H-LIN
Price: 1 USD

China 19" 1U Rack Mounted Optical Plc Splitter 1x16 Cold Rolled Steel Material factory

Brand Name : H-LIN

Model Number : HL-Rack

Certification : CE/ROHS/IOS9001

Place of Origin : Shenzhen China

MOQ : 1 Piece/Pieces

Price : negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 2000 Piece/Pieces per Month

Delivery Time : 3~5working days after payment

Packaging Details : 1pcs per box

Type : Rack Mounted

Connector Type : FC/UPC

Fiber Type : G.657A or Customized

Material : Cold Rolled Steel

Output Fiber Length : Standard 1m, can be customized

Input/output cable diameter : 0.25mm or 0.9mm or 2.0mm or 3.0

Contact Now

1U 19' Rack mount PLC fiber optic splitter 1 to 16

Description

Fiber optic LC splitter is an optical power device based on quartz plate planar of light wave technology, which is widely used in local side or termination of Passive Optical Network (EPON, BPON, GPON etc.) for splitting of optical signal. It offers superior optical performance, high stability and high reliability; meet various application requirements in different environments.

Optical Parameter

Description	Unit	1x2	1x4	1x8	1x16	1x32	1x64
Operating Wavelength(nm)	nm	1260 ~ 1650nm
Insertion Loss(dB)	P	3.8	7.0	10.1	13.3	16.7	19.9
Insertion Loss(dB)	S	3.9	7.15	10.25	13.55	16.85	20.15
Loss Uniformity(dB)	P	0.6	0.6	0.6	0.8	1.4	1.8
Loss Uniformity(dB)	S	0.8	0.8	0.8	1.0	1.5	2
Polarization Dependent Loss(dB)	P	0.2	0.2	0.2	0.2	0.2	0.3
Polarization Dependent Loss(dB)	S	0.3	0.3	0.3	0.3	0.3	0.5
Return Loss	Min	55
Derectivity	Min	UPC:50 APC:55
Operating Temperature(℃)		- 40 ~ +85
Storage Temperature(℃)		- 40 ~ +85

Features

Low Insertion loss
Low PDL
High Return Loss
Uniform Power Splitting
Compact Design
Wide Operating Wavelength
Wide Operating Temperature
ExcellentEnvironmental & Mechanical Stability
Qualified Under Telcordia GR-1221 and GR-1209

Applications

FTTX(FTTP,FTTH,FTTN,FTTC)

Passive Optical Networks(PON)

Local Area Networks(LAN)

CATV Systems

Test Equipments

Product details

Cup protects the socket to prevent foreign matter from entering and reduces the optical property.

Packing

19" 1U Rack Mounted Optical Plc Splitter 1x16 Cold Rolled Steel Material
